RG-NBS6002 Commutateur administrable dans le cloud de niveau 3

Entreprise, hôtel, usine, éducation, commerce de détail, etc.

Modèles
RG-NBS7003

3 emplacements de service,2 emplacements d'alimentation

 RG-NBS7006

6 emplacements de service,2 modules de moteur de superviseur

 RG-NBS6002

2 emplacements de service,2 emplacements d'alimentation,2 ventilateurs
Séries
Châssis/ Switch modulaire L3 Switch 10G Up L3 fixe Switch 1G Up L3 fixe
Datasheet Sales Enquiry
Add to Favorites
Fonctionnalités particulières
  • La conception modulaire garantit l'évolutivité et la flexibilité
  • Redondance de haut niveau, garantissant un service ininterrompu
  • Solution de réseau entier spécialement conçue pour les PME
  • Gestion à vie sur le Ruijie Cloud à tout moment et en tout lieu
Sales Enquiry
Caractéristiques

RG-NBS6002
Commutateur de cœur de réseau modulaire à deux emplacements

  • 4 cartes
    ligne en option
  • 32,000
    Adresse MAC
  • 8,000
    Table ARP
  • 176Gbps
    Capacité de commutation
  • 132Mpps
    Capacité de transfert de paquets

Commutateur de cœur de réseau très compétitif

Profiter de la performance de deux pour le prix d'un

Conception modulaire : Hautes performances, évolutivité et flexibilité

Prise en charge de 4 types de cartes ligne, 11 combinaisons

Redondance de haut niveau, garantissant un service ininterrompu

  • Modules redondants
  • Commutation de cluster virtuel (VCS)

2 emplacements d'alimentation : continuité de service assurée

Commutation de cluster virtuel (VCS) : basculement du service en 500 ms

Cloud, simplifier votre business

  • SON, provisionning sans contact vers le Cloud
  • Surveiller les statistiques de commutateur à tout moment et en tout lieu
  • Configurer les VLAN sur l'application Ruijie Cloud
  • Maintenance facile, gain de temps et moins de déplacement sur site

Key Specifications
Product Information
Product Category
Product Category
  • Layer 3
Hardware Specifications
Product Information
Warranty
  • 5 years
Port Specifications
Total number of RJ45 ports
  • Determine the quantity based on the type and number of line cards.
Total number of optical ports
  • No
Number of 1GE combo ports
  • No
Number of 1GE SFP ports
  • No
Number of 10GE SFP+ ports
  • Determine the quantity based on the type and number of line cards.
Number of 10/100BASE-T ports
  • No
Number of 10/100/1000BASE-T ports
  • Determine the quantity based on the type and number of line cards.
Number of 10/100/1000/2500BASE-T ports
  • No
Number of 100/1000/2.5G/5G/10GBASE-T ports
  • No
System Specifications
Forwarding rate
  • 130.94 Mpps
Switching capacity
  • 176 Gbps(bit/s)
Environment and Reliability
MTBF
  • 400,000 hours
Operating temperature
  • 0°C to +50°C (32°F to 122°F)
Altitude
  • Operating altitude: –500 m to +5,000 m (–1,640.42 ft. to +16,404.20 ft.)
    Storage altitude: –500 m to +5,000 m (–1,640.42 ft. to +16,404.20 ft.)
Surge protection
  • Service port: ±6 kV for common mode
    Power connector: ±6 kV for both common mode and differential mode
Software Specifications
Basic Configurations
PoE watchdog
  • No
Interface
Jumbo frame length (MTU)
  • 9216 bytes (interface configuration mode)
Security
Port isolation
  • Yes
Broadcast storm control
  • Yes
Applications
