RG-ES126S-P V2, 24-Port 10/100 Mbps with 2-Port Gigabit Rackmount PoE Switch

Home Office, Retails, Cafe, Villa etc.

Models
RG-ES105D

5 FE

 RG-ES105GD

5 GE

 RG-ES106D-P V2

6 FE, 54W

 RG-ES106F-P

6 FE,54 W

 RG-ES108D

8 FE

 RG-ES110D-P

8 FE, 2 GE, 110W

 RG-ES108GD

8 GE

 RG-ES110GS-P-L

9 GE,1 SFP,120 W

 RG-ES110FG-P

8 FE,2 GE,110 W

 RG-ES110GDS-P

8 GE, 2 SFP, 120W

 RG-ES110F-P

10FE,110W

 RG-ES116G

16 GE

 RG-ES118S-LP

16 FE, 2 GE, 120W

 RG-ES118FGS-LP

16 FE,2 GE,120 W

 RG-ES116G-L

16 GE

 RG-ES118GS-P

16 GE, 2 SFP, 247W

 RG-ES126FGS-P

24 FE,2 GE,370 W

 RG-ES126FGS-LP

24 FE,2 GE,180 W

 RG-ES118GS-P-L

16 GE,2 SFP,247 W

 RG-ES124GD

24 GE

 RG-ES126S-P V2

24 FE, 2 GE, 370W

 RG-ES126S-LP V2

24 FE, 2 GE, 180W

 RG-ES124G-L

24 GE
Series
Metal Casing Plastic Casing
Datasheet Sales Enquiry
Add to Favorites
Highlight Features
  • Unmanaged switch, which is visible on Ruijie Cloud APP
  • Large buffer for smooth data transmission
  • Intelligent PoE management
  • High network reliability
  • High-quality design
  • Adaptation to various scenarios
Sales Enquiry
Key Specification
Ports
24 x 10/100Base-X PoE+ ports, 2 x 10/100/1000Base-T ports
Layer type
Unmanaged
Switching capacity
8.8 Gbps
Forwarding rate
6.55 Mpps
MAC address table
8000
Fan
Support
Port surge
6 kV
Dimensions (W x D x H)
440 mm × 208 mm × 44 mm
Weight (With package)
3 kg
Warranty
3 Years
Certification
CE
Features


RG-ES126S-P

24-Port 10/100Mbps, 2-Port Gigabit Unmanaged Switch with 24 PoE+ Ports

  • Plug & Play

  • PoE 370W

  • 3-Year Warranty

Unmanaged Switch, Which Is Visible on Ruijie Cloud APP*

Large Buffer for Smooth Data Transmission

Hardware flow control, guarantee the large buffer

Intelligent PoE Management

Application to various powered devices (PDs), single port with up to 30 W

High Network Reliability

Stability without frequent restart

  • Fanfree and quiet design

  • Green (802.3az)

  • Energy Saving

High-Quality Design

Strict standards in PCB design and component selection

Adaptation to Various Scenarios

Comparison
Downlink Ports
Uplink Ports
PoE/PoE+ ports
Max. PoE budget
Layer Type
Switching capacity
Forwarding rate
MAC address table
Dimensions (W x D x H)
Weight (With package)
Warranty
Auto/Full/Half Duplex Negotiation
Auto MDI/MDIX
Switching model
Cloud Management
Reset Button
Flow Control
Port Isolation
Power Consumption
Power Supplies
Surge Protection
Fan
Operating Temperature
Storage Temperature
Operating Humidity
Storage Humidity
MTBF
Certificate
RG-ES126S-P V2
24 x 10/100BASE-TX
2 x 10/100/1000BASE-T with 1 Combo port
24
370W
Unmanaged
8.8 Gbps
6.55 Mpps
16000
440 mm × 208 mm × 44 mm
3 kg
3 Years
Store-and-forward
Cloud monitoring
<220W
100V AC to 240V AC, 4A
6kV
Support
0°C to 45°C (32°F to 109°F)
-40°C to 70°C (-40°F to 158°F)
10% to 90% RH
5% to 95% RH
> 200,000
CE, RoHS
RG-ES105D
5 x 10/100BASE-TX
Unmanaged
1 Gbps
744 Kpps
1000
119 mm x 75 mm x 24 mm
0.25 kg
3 Years
Store-and-forward
Cloud monitoring
≤5W
5V power adapter, 1A
6kV
Fanless
0°C to 40°C (32°F to 104°F)
-40°C to 70°C (-40°F to 158°F)
10% RH to 90% RH
5% RH to 95% RH
> 200,000
CE, RoHS
RG-ES108D
8 x 10/100BASE-TX
Unmanaged
1.6 Gbps
1.19 Mpps
2000
160 mm x 75 mm x 24 mm
0.35 kg
3 Years
Store-and-forward
Cloud monitoring
≤5W
5V power adapter, 1A
6kV
Fanless
0°C to 40°C (32°F to 104°F)
-40°C to 70°C (-40°F to 158°F)
10% RH to 90% RH
5% RH to 95% RH
> 200,000
CE, RoHS
RG-ES106D-P V2
4 x 10/100BASE-TX
2 x 10/100BASE-TX
4
58W
Unmanaged
1.2 Gbps
0.89 Mpps
2000
140 mm × 67 mm × 26 mm
0.66 kg
3 Years
Store-and-forward
Cloud monitoring
＜67W
51V DC Power adapter, 1.25A
6kV
Fanless
0°C to 45°C (32°F to 109°F)
-40°C to 70°C (-40°F to 158°F)
10% RH to 90% RH
5% RH to 95% RH
> 200,000
CE, RoHS
RG-ES110D-P
8 x 10/100BASE-TX
2 x 10/100/1000BASE-T
8
110W
Unmanaged
5.6 Gbps
4.17 Mpps
2000
190 mm × 100 mm × 28 mm
1.3 kg
3 Years
Store-and-forward
Cloud monitoring
<129W
53V DC Power adapter, 2.24A
6kV
Fanless
0°C to 45°C (32°F to 109°F)
-40°C to 70°C (-40°F to 158°F)
10% RH to 90% RH
5% RH to 95% RH
> 200,000
CE, RoHS
RG-ES118S-LP
16 x 10/100BASE-TX
2 x 10/100/1000BASE-T with 1 Combo port
16
120W
Unmanaged
7.2 Gbps
5.36 Mpps
8000
440 mm × 208 mm × 44 mm
3.4 kg
3 Years
Store-and-forward
Cloud monitoring
<148W
100V AC to 240V AC, 2.5A
6kV
Fanless
0°C to 45°C (32°F to 109°F)
-40°C to 70°C (-40°F to 158°F)
10% to 90% RH
5% to 95% RH
> 200,000
CE, RoHS
RG-ES126S-LP V2
24 x 10/100BASE-TX
2 x 10/100/1000BASE-T with 1 Combo port
24
180W
Unmanaged
8.8 Gbps
6.55 Mpps
16000
440 mm × 208 mm × 44 mm
3 kg
3 Years
Store-and-forward
Cloud monitoring
<220W
100V AC to 240V AC, 4A
6kV
Support
0°C to 45°C (32°F to 109°F)
-40°C to 70°C (-40°F to 158°F)
10% to 90% RH
5% to 95% RH
> 200,000
CE, RoHS
RG-ES105GD
5 x 10/100/1000BASE-T
Unmanaged
10 Gbps
7.44 Mpps
2000
119 mm x 75 mm x 24 mm
0.25 kg
3 Years
Store-and-forward
Cloud monitoring
≤5W
5V power adapter, 1A
6kV
Fanless
0°C to 40°C (32°F to 104°F)
-40°C to 70°C (-40°F to 158°F)
10% to 90% RH
5% to 95% RH
> 200,000
CE, RoHS
RG-ES108GD
8 x 10/100/1000BASE-T
Unmanaged
16 Gbps
11.9 Mpps
4000
160 mm x 75 mm x 24 mm
0.35 kg
3 Years
Store-and-forward
Cloud monitoring
≤5W
5V power adapter, 1A
6kV
Fanless
0°C to 40°C (32°F to 104°F)
-40°C to 70°C (-40°F to 158°F)
10% to 90% RH
5% to 95% RH
> 200,000
CE, RoHS
RG-ES110GDS-P
8 x 10/100/1000BASE-T
2 x 1000BASE-X SFP
8
120W
Unmanaged
20 Gbps
14.88 Mpps
4000
280 mm x 180 mm x 44 mm
2.26 kg
3 Years
Store-and-forward
Cloud monitoring
≤130W
100V AC to 240V AC, 2.5A
6kV
Fanless
0°C to 45°C (32°F to 109°F)
-40°C to 70°C (-40°F to 158°F)
10% to 90% RH
5% to 95% RH
> 200,000
CE, RoHS
RG-ES116G
16 x 10/100/1000BASE-T
Unmanaged
32 Gbps
23.81 Mpps
8000
280 mm x 126 mm x 44 mm
1.75 kg
3 Years
Store-and-forward
Cloud monitoring
≤11W
100V AC to 240V AC, 0.5A
6kV
Fanless
0°C to 45°C (32°F to 109°F)
-40°C to 70°C (-40°F to 158°F)
10% to 90% RH
5% to 95% RH
> 200,000
CE, RoHS
RG-ES118GS-P
16 x 10/100/1000BASE-T
2 x 1000BASE-X SFP
8
247W
Unmanaged
36 Gbps
26.78 Mpps
8000
440 mm x 240 mm x 44 mm
4.0 kg
3 Years
Store-and-forward
Cloud monitoring
≤285W
100V AC to 240V AC, 3.5A
6kV
Support
0°C to 45°C (32°F to 109°F)
-40°C to 70°C (-40°F to 158°F)
10% to 90% RH
5% to 95% RH
> 200,000
CE, RoHS
RG-ES124GD
24 x 10/100/1000BASE-T
Unmanaged
48 Gbps
35.71 Mpps
8000
280 mm x 126 mm x 44 mm
1.76 kg
3 Years
Store-and-forward
Cloud monitoring
≤16W
100V AC to 240V AC, 0.5A
6kV
Fanless
0°C to 45°C (32°F to 109°F)
-40°C to 70°C (-40°F to 158°F)
10% to 90% RH
5% to 95% RH
> 200,000
CE, RoHS
