Elevator, Campus, Building, etc.
Performance
Scenarios
Stable Signal for Wireless
Connection
Higher Reliability, Lower Failure Rate
Easy Recognition in the Dark
Visually Statistics Monitoring on Ruijie Cloud
| Model | Mode | Bridging Performance | RSSI | Recommended Number of Cameras | |||
| 3 MP | 4 to 5 MP | 6 to 7 MP | 7 to 8 MP | ||||
| RG-EST100-E | PTP 1 x RG-EST100-E + 1 x RG-EST100-E |
60 Mbps/100 meters (HT20) 30 Mbps/500 meters (HT20) |
–58 dBm/100 m –68 dBm/500 m |
10/100 m 5/500 m |
6/100 m 3/500 m |
3/100 m 1/500 m |
3/100 m 1/500 m |
| RG-EST310 V2 | PTP 1 x RG-EST310 V2 + 1 x RG-EST310 V2 |
90 Mbps/100 meters (HT40) 80 Mbps/500 meters (HT40) 80 Mbps/1 km (HT40) |
–52 dBm/100 m –65 dBm/500 m –68 dBm/1 km |
16/100 m 16/500 m 16/1 km |
10/100 m 10/500 m 10/1 km |
7/100 m 7/500 m 7/1 km |
5/100 m 5/500 m 5/1 km |
| RG-EST350 V2 | PTP 1 x RG-EST350 V2 + 1 x RG-EST350 V2 |
230 Mbps/1 km (HT40) 200 Mbps/3 km (HT40) 150 Mbps/5 km (HT40) |
–58 dBm/1 km –66 dBm/3 km –70 dBm/5 km |
50/1 km 45/3 km 20/5 km |
30/1 km 25/3 km 12/5 km |
20/1 km 13/3 km 8/5 km |
15/1 km 12/3 km 6/5 km |
| RG-AirMetro460G | PTP 1 x RG-AirMetro460G + 1 x RG-AirMetro460G |
230 Mbps/1 km (HT40) 200 Mbps/3 km (HT40) 150 Mbps/5 km (HT40) 80 Mbps/10 km (HT40) |
–58 dBm/1 km (HT40) –66 dBm/3 km (HT40) –70 dBm/5 km (HT40) –78 dBm/10 km (HT40) |
50/1 km 45/3 km 20/5 km 16/10 km |
30/1 km 25/3 km 12/5 km 8/10 km |
20/1 km 13/3 km 8/5 km 5/10 km |
15/1 km 12/3 km 6/5 km 4/10 km |
| RG-AirMetro460F | PTP 1 x RG-AirMetro460F + 1 x RG-AirMetro460F |
80 Mbps/1 km (HT40) 80 Mbps/3 km (HT40) 70 Mbps/5 km (HT40) 50 Mbps/10 km (HT40 |
–58 dBm/1 km (HT40) –66 dBm/3 km (HT40) –70 dBm/5 km (HT40) –78 dBm/10 km (HT40) |
12/1 km 12/3 km 10/5 km 6/10 km |
8/1 km 8/3 km 6/5 km 4/10 km |
6/1 km 6/3 km 5/5 km 3/10 km |
4/1 km 4/3 km 3/5 km 2/10 km |
| RG-AirMetro550G-B+ RG-ANT13-360 |
PTMP 1 x RG-AirMetro550G-B + N x RG-AirMetro460G 2≤N≤32 |
179 Mbps/1 km (HT40) 111 Mbps/2 km (HT40) |
-61 dBm/1 km(HT40) -67 dBm/2 km(HT40) |
41/1 km 26/2 km |
25/1 km 15/2 km |
18/1 km 11/2 km |
15/1 km 9/2 km |
| RG-AirMetro550G-B+ RG-ANT16S-120 |
PTMP 1 x RG-AirMetro550G-B + N x RG-AirMetro460G 2≤N≤32 |
204 Mbps/1 km (HT40) 153 Mbps/3 km (HT40) 94 Mbps/5 km (HT40) |
-58 dBm/1 km (HT40) -66 dBm/3 km (HT40) -72 dBm/5 km (HT40) |
47/1 km 35/3 km 22/5 km |
28/1 km 21/3 km 13/5 km |
20/1 km 15/3 km 9/5 km |
17/1 km 13/3 km 8/5 km |
| RG-AirMetro550G-B+ RG-ANT20S-90 |
PTMP 1 x RG-AirMetro550G-B + N x RG-AirMetro460G 2≤N≤32 |
204 Mbps/3 km (HT40) 153 Mbps/5 km (HT40) 77 Mbps/10 km (HT40) |
-60 dBm/3 km (HT40) -66 dBm/5 km (HT40) -73 dBm/10 km (HT40) |
47/3 km 35/5 km 18/10 km |
28/3 km 21/5 km 10/10 km |
20/3 km 15/5 km 7/10 km |
17/3 km 13/5 km 6/10 km |
| RG-AirMetro550G-B+ RG-ANT13-360 |
PTMP 1 x RG-AirMetro550G-B + N x RG-AirMetro460F 2≤N≤32 |
162 Mbps/1 km (HT40) 100 Mbps/2 km (HT40) |
-61 dBm/1 km(HT40) -67 dBm/2 km(HT40) |
37/1 km 23/2 km |
22/1 km 14/2 km |
16/1 km 10/2 km |
14/1 km 8/2 km |
| RG-AirMetro550G-B+ RG-ANT16S-120 |
PTMP 1 x RG-AirMetro550G-B + N x RG-AirMetro460F 2≤N≤32 |
185 Mbps/1 km (HT40) 139 Mbps/3 km (HT40) 85 Mbps/5 km (HT40) |
-58 dBm/1 km (HT40) -66 dBm/3 km (HT40) -72 dBm/5 km (HT40) |
43/1 km 32/3 km 19/5 km |
26/1 km 19/3 km 12/5 km |
18/1 km 14/3 km 8/5 km |
16/1 km 12/3 km 7/5 km |
| RG-AirMetro550G-B+ RG-ANT20S-90 |
PTMP 1 x RG-AirMetro550G-B + N x RG-AirMetro460F 2≤N≤32 |
185 Mbps/3 km (HT40) 139 Mbps/5 km (HT40) 69 Mbps/10 km (HT40) |
-60 dBm/3 km (HT40) -66 dBm/5 km (HT40) -73 dBm/10 km (HT40) |
43/3 km 32/5 km 16/10 km |
26/3 km 19/5 km 9/10 km |
18/3 km 14/5 km 7/10 km |
16/3 km 12/5 km 6/10 km |
