RG-EG105G-P-V3 Reyee Cloud Managed PoE Router

Office, Hotel, School, Retail, CCTV, Home, etc.

Models
RG-EG105G-V3

802.1X authentication,SNMP,dynamic routing

 RG-EG105G-P-V3

802.1X authentication,SNMP,dynamic routing

 RG-EG105G V2

5 Gigabit Ports,100 Users,600Mbps

 RG-EG105G-P V2

5 Gigabit Ports, 4 PoE+ Out, 100 Users, 600Mbps
Series
EG100 Series EG1500 Series EG200 Series EG300 Series
Datasheet Sales Enquiry
Add to Favorites
Highlight Features
  • Unified Features with Upgraded Flash Storage
  • User-friendly configuration and easy to use
  • High reliability and load balancing through WAN ports
  • Easy to block unwanted applications with automatically updating library
  • Customized portal page, what you see is what you get (WYSIWYG)
  • Secure access to internal devices remotely
Sales Enquiry
Key Specification
Network Interface
5 × 10/100/1000 Base-T
Max. WAN Ports
2 × 10/100/1000 Base-T
Throughput
600 Mbps (1518 Byte, NAT+Flow Audit) 500 Mbps (1518 Byte, NAT+Authentication, Application Identification, Flow Audit and Flow Control) 1000 Mbps (Turbo Mode)
Recommended Concurrent Clients
100
PoE Out
802.3af/at on LAN 0-3
Operating Temperature
0°C~40°C
CPU
2 Cores, 880 MHz
RAM
128 MB
Flash Memory
32 MB
Power Consumption
<60 W (With PoE Full Load)
Dimensions(W×D×H)
206.5 mm × 108.5 mm × 28 mm
Weight
0.406 kg (packages not included)
Installation
Desk-mounted, Wall-mounted
Warranty
3 Years
Certification
CE, RoHS
Features

Simplified Configuration and Powerful Features

Powerful features for small-sized networks, and simplified configuration.
Interface
Installation
Dual-WAN
Load Balancing
IPSec, OpenVPN,
PPTP, L2TP, etc.
Captive
Portal
Free Cloud
Management
3-Year
Warranty

User-friendly
configuration,
and Easy to Use

EAdvanced functions can be also
easily configured through Ruijie Reyee APP.

Highly Reliable Multi-WAN Internet

Intelligent load balancing and link redundancy between multiple WAN ports.
Seamless
Failover
Aggregated
Bandwidth
Automatic
Setup
Customizable
Link Weight

Easy to Block Unwanted Applications

Automatically updated APP library, maintenance-free.

Customized Portal Page,
What You See is What You Get

Secure Access to
Internal Device Remotely

Secure monitoring of NVR/IPC/internal server anywhere and anytime.

Cloud,
Make Your
Business
Easy

  • Self-organizing network (SON)
  • Centralized network management
  • Scenario-based configuration
  • Cloud portal authentication
  • Remote monitoring and maintenance



Comparison
WAN Port(s)
LAN Port(s) (including switchable port)
LAN/WAN Switchable Port
CPU
RAM
Flash
Recommended Throughput
Recommended Concurrent Users
Max VLAN
No. of Devices Managed in Router Mode
No. of Devices Managed in AC Mode
PoE/PoE+
PoE Power Budget,Max.
Captive Portal
PPPoE Server
Max PPPoE Active Client
Smart Flow Control
Application Based Speed Limit
Key Application Priority
User Group Based Speed Limit
Key User Priority
Behavior Management
VPN
Max IPSec Active Tunnels
Max PPTP Active Tunnels
Max L2TP Active Tunnels
Max L2TP Over IPSec Active Tunnels
Max OpenVPN Active Tunnels
Basic Firewall
SNMP Service
Management
Power Consumption
Power Supply
Weight
Dimensions and Rack Units
Certifications
Warranty
RG-EG105G-V3
1×10/100/1000 Base-T
4×10/100/1000 Base-T
1×10/100/1000 Base-T
Dual Core, 880MHz
128MB
32 MB
600Mbps
100
16
32 (APs/NBS Switches) +128 (ES Switches)
300 (APs/NBS Switches) +128 (ES Switches)
35
PPTP, L2TP, IPsec, OpenVPN
8
8
8
8
16
Cloud APP, Cloud Web, Eweb
<12 W
DC 12V/1A (Adapter included)
0.406 kg (packages not included)
206.5 mm × 108.5 mm × 28 mm
CE, ROHS
3 Years
RG-EG105G V2
1×10/100/1000 Base-T
4×10/100/1000 Base-T
1×10/100/1000 Base-T
Dual Core, 880MHz
128MB
16 MB
600Mbps
100
16
32 (APs/NBS Switches) +128 (ES Switches)
300 (APs/NBS Switches) +128 (ES Switches)
35
PPTP, L2TP, IPsec, OpenVPN
8
8
8
8
16
Cloud APP, Cloud Web, Eweb
<12 W
DC 12V/1A (Adapter included)
0.406 kg (packages not included)
206.5 mm × 108.5 mm × 28 mm
CE, ROHS
3 Years
RG-EG105G-P-V3
1×10/100/1000 Base-T
4×10/100/1000 Base-T
1×10/100/1000 Base-T
Dual Core, 880MHz
128MB
32 MB
600Mbps
100
16
32 (APs/NBS Switches) +128 (ES Switches)
300 (APs/NBS Switches) +128 (ES Switches)
54 W
35
PPTP, L2TP, IPsec, OpenVPN
8
8
8
8
16
Cloud APP, Cloud Web, Eweb
<60 W (With PoE Full Load)
DC 54V/1.1A (Adapter included)
0.406 kg (packages not included)
206.5 mm × 108.5 mm × 28 mm
CE, ROHS
3 Years
RG-EG210G-P-V3
1×10/100/1000 Base-T
9×10/100/1000 Base-T
3×10/100/1000 Base-T
Dual Core, 880MHz
256MB
32 MB
600Mbps
200
32
150 (APs/NBS Switches) +128 (ES Switches)
500 (APs/NBS Switches) +128 (ES Switches)
110 W
65
PPTP, L2TP, IPsec, OpenVPN
8
8
8
8
16
Cloud APP, Cloud Web, Eweb
<130 W (With PoE Full Load)
DC 54V/2.4A (Adapter included)
0.522kg (packages not included)
202 mm × 108 mm × 28 mm
CE, ROHS
3 Years
RG-EG209GS
1×10/100/1000 Base-T
7×10/100/1000 Base-T
1×1GBase-X SFP
2×10/100/1000 Base-T
1×1GBase-X SFP
Dual Core, 880MHz
256MB
32MB
600Mbps
200
32
150 (APs/NBS Switches) +128 (ES Switches)
500 (APs/NBS Switches) +128 (ES Switches)
65
PPTP, L2TP, IPsec, OpenVPN
8
8
8
8
16
Cloud APP, Cloud Web, Eweb
<18 W
DC 12V/1.5A (Adapter included)
0.5 kg
202 mm x 108 mm x 28 mm
CE, ROHS
3 Years
